CADRE
HPA Advanced Hydroform, ATG, ETC 4-Link, AXH
TAILLE
Size Split: 27.5: XS // 29: S, M, L, XL
FOURCHE
RockShox Judy Silver TK Air, Tapered, 15x110mm, 130mm
AMORTISSEUR
Manitou Radium Expert RL, 190x45mm, Rebound Adjust, Lockout
ENTRETOISES D’AMORTISSEUR
Top: 40x8mm, Bottom: 22x8mm
FREIN
Magura MT Thirty, Front 2-Piston/Rear 2-Piston, Hydr. Disc Brake (180/180)
DÉRAILLEUR ARRIÈRE
Sram NX Eagle™, 12-Speed
LEVIERS
Sram SX Eagle™ Trigger
PLATEAU
Sram X1 1000 Eagle™ DUB 30T, Boost, 175mm (170mm for XS/S)
CASSETTE
Sram PG-1210 Eagle™, 11-50T
CHAÃŽNE
Sram SX Eagle™
MOYEU AVANT
Shimano HB-MT400-B, 15mm, Boost, Centerlock
MOYEU ARRIÈRE
Shimano FH-MT400-B, 12mm, Boost, Centerlock
JANTES
CUBE EX25, 32H, Disc
PNEUS
Schwalbe Nobby Nic, Addix Performance, Kevlar, 2.4
POTENCE
Newmen Evolution 318.4, 31.8mm
CINTRE
Newmen Evolution SL 318.25, 760mm
POIGNÉES
ACID React Pro
TIGE DE SELLE
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm, (XS: 100mm, S: 120mm, M/L/XL: 130mm)
COLLIER DE SELLE
CUBE Screwlock, 34.9mm
SELLE
Natural Fit Venec Lite
JEU DE DIRECTION
VP Tapered, Top Zero-Stack 1 1/8″ (OD 44mm), Bottom Zero-Stack 1 1/2″ (OD 56mm)
POIDS
14,8 kg
COULEUR
grey´n´orange
