cadreHPA Ultralight, Advanced Hydroforming, Triple Butted, ETC 4-Link, AXH
tailleSize Split: 27.5: 13,5″, 16″ // 29: 17″, 19″
fourcheSR Suntour XCR32 Air Disc, 120mm,
jeu de directionFSA 1.5E ZS, Tapered, Top Zero-Stack 1 1/8″ (OD 44mm), Bottom Zero-Stack 1 1/2″ (OD 56mm)
potenceCUBE Performance Stem Pro, 31.8mm
cintreCUBE Rise Trail Bar, 700mm
poignéesCUBE Performance Grip
dérailleur arrièreShimano XT RD-M781-DSGSL, Shadow, 10-Speed
dérailleur avantShimano Deore FD-M617-D, Direct Mount, Side Swing
leviersShimano Deore SL-M6000, Rapidfire-Plus
freinShimano BR-MT200, Hydr. Disc Brake (180/180)
plateauShimano Deore FC-M617, 36x22T, 175mm
chaîneKMC X10
couleurlightblue´n´coral
amortisseurSuntour UNAir LOR8, 184x44mm
cassetteShimano CS-HG50, 11-36T
moyeu avantShimano HB-MT400, 15QR, Boost
moyeu arrièreShimano FH-MT400, Through Axle
jantesCUBE EX21, 32H, Disc
pneu arrièreSchwalbe Rapid Rob, Active, 2.25
selleNatural Fit Active WS
tige de selleCUBE Performance Post, 31.6mm
collier de selleCUBE Varioclose, 34.9mm
pneu avantSchwalbe Tough Tom, Active, 2.25
entretoises d’amortisseurTop: 30x8mm, Bottom: 22x8mm
13,8 kg
