CADRE
C:68 Monocoque Advanced Twin Mold Technology, ATG, ETC 4-Link, ISCG Mount, Boost 148, AXH
COULEUR
carbon´n´red
FOURCHE
RockShox Lyrik Ultimate RC2, 110x15mm, Tapered, 160mm
AMORTISSEUR
RockShox Super Deluxe Ultimate DebonAir, 185x55mm, Trunnion Mount
JEU DE DIRECTION
FSA Orbit I-t, Integrated, Top 1 1/8″, Bottom 1 1/2″
POIDS
12,9 kg
TRANSMISSION
DÉRAILLEUR ARRIÈRE
Sram X01 Eagle™, 12-Speed
PÉDALIER
Sram X01 Eagle™ Carbon 30T, Boost, 170mm
CASSETTE
Sram XG-1295, 10-50T
CHAÎNE
Sram PC-X01 Eagle™
MANETTES DE DÉRAILLEUR
Sram X01 Eagle™ Trigger
FREINS
FREINS
Sram G2 Ultimate, Hydr. Disc Brake (200/180)
ROUES
PNEU AVANT
Maxxis Minion DHF, MaxxTerra/EXO, Tubeless Ready, 29 x 2.5 WT
PNEU ARRIÈRE
Maxxis Minion DHR II, MaxxTerra/EXO, Tubeless Ready, 29 x 2.4 WT
POSTE DE PILOTAGE
POTENCE
Race Face Turbine R 35
CINTRE
Race Face Next R 35 Carbon, 800mm
GRIPS
CUBE Race SL Grip 29.5mm, 1-Clamp
SELLE
SDG Radar
TIGE DE SELLE
RockShox Reverb Stealth 1X, 31.6mm, 414x150mm (351x125mm for smallest frame size)
